Part No. 3T3-700
Reg Price $259.95
SALE PRICE $225.00
A quality name you can trust !
2MHz Function Generator
Wavetek Model FG2
* VCF input * Inversion
* 7 Ranges, 0.2Hz to 2MHz
* Duty cycle control
* Variable/Fixed attenuators
* Variable DC offset control
The FG2 Function Generator offers a variety of high performance capabilities including fast, easy pushbutton selection of power, frequency range and waveform. Standard outputs include both TTL pulse outputs and an adjustable low impedance output that provides low distortion sine, square or triangle wave signals. Duty cycle control. Invert button changes polarity. VCF input to control frequency by an external DC control voltage. 20dB attenuator. In short, the FG2 is everything you would like it to be!
SPECIFICATIONS:
Power Consumption: 15VA max. at 117VAC. Frequency Ranges (with setting at): 1 0.2Hz to 2.0Hz; 10 2Hz to 20Hz; 100 20Hz to 200Hz; 1K 0.2KHz to 2.0KHz; 10K 2KHz to 20KHz; 100K 20KHz to 200KHz; 1M 0.2MHz to 2.0MHz. Freq. Multiplier: 0.2 to 2.0. Freq. Accuracy: +-5%FS. Voltage Controlled Freq. Range: 1000:1 min. for 0 to 10 +-1V input; 1:1000 min. for 0 to -10 +-1V input. Input Impedance: 10K ohm +-10% Sinewave Distortion: less than 1% for freq. below 200Khz. All harmonics 20dB down min. Square Wave Rise/Fall Time: less than 100nS. Pulse Output Rise/Fall Time: less than 25nS (5TTL loads). Main Output: Amplitude: less than 20Vp-p (open circuit); less tha 10Vp-p (into 50 ohm load); Impedance: 50 ohms +-6%. Amplitude Adj.: less than 632mV p-p to less than 20V p-p open circuit (20dB attenuator off). Attenuator: -20dB +-10dB. DC Offset Control: less than -10V to less than +10V (open circuit); less than -5V to less than +5V (into 50 ohm load). Duty Cycle Control (50% at Max. CCW Position): 5 to 1 min. duty cycle change. Dimensions (HxWxD): 85 x 235 x 280mm. Weight: 3.5 lb. (1.5kg). Accessories: two test leads, AC power cord, three fuses (one installed).
